Discontinuation of The Cyclops-7 Logger
As a result of Turner Designs discontinuing their Cyclops-7 product line PME will no longer offer the Cyclops-7 logger BUT WE are excited to offer the C-FLUOR Logger. The Smarter Fluorometer Choice.
For customers with existing Cyclops-7 Loggers, PME will continue to offer technical support and service for as long as feasible.
The C-Fluor Logger, Optimized for reliability, performance, and ease of use.
The Fixed and Interchangeable C-FLUOR Logger connects seamlessly with Turner Designs' C-FLUOR sensors, offering users maximum flexibility in measurement capabilities. Programmable sample intervals collect and record data internally. Data is easily transferred for analysis via standard USB cable connection. Completely self-contained and waterproof, the C-FLUOR boast a battery capacity of up to 200,000 samples before requiring replacement.
The Cyclops-7 Logger is designed for the Turner Designs Cyclops sensors. The Interchangeable and Fixed Cyclops-7 Logger offers users maximum flexibility in measurement capabilities. User-determined sample intervals collect and record water quality data internally. Data is transferrable via a standard USB cable, and upon connection, the logger will automatically adjust for sensor gain based on measurement conditions.
Parameters
Product Options
Fixed Sensor Option
The Fixed Cyclops-7 Logger connects to one Turner Designs Cyclops-7 sensor. The sensor is permanently installed on the Fixed Cyclops-7 Logger and cannot be removed by the user.
Interchangeable Sensor Option
The Interchangeable Cyclops-7 Logger connects to one Turner Designs Cyclops-7 sensor at a time. Sensors are removable and can be interchanged by the user.
Calibration
Every Cyclops-7 sensor must be calibrated before use. The Cyclops-7 Logger software allows users to easily calibrate the sensor, but it is recommended that standards be purchased from either PME or Turner Designs. These standards serve as references for calibrating the sensor.
Logger Information
The logger is completely self-contained and waterproof. Internal power allows the logger to operate for roughly 28,000 samples. Logger is constructed of a hard, durable plastic material that does not easily crack or break. All internal circuitry and sensor components have been specifically designed to fit on the logger spine. The batteries, SD card, on/off switch, circuit board and various other components are attached to a chem film aluminum spine. The Cyclops-7 has a 100-meter depth rating and software allows users to create visual plots of data collected.
| Sample Interval Minutes | Days of Sampling | Number of Samples |
|---|---|---|
| 1 | 20 | 28,800 |
| 10 | 200 | 28,800 |
| 60 | 365 | 28,800 |
